HARNESS LAYOUT — Engine Room Harness (Cont'd)
EL-98wiring diagramR.H. Drive Model only — this page shows engine room harness layout specific to right-hand drive configuration.
Engine Room Harness (Cont'd)
R.H. DRIVE MODEL
Component LocationFig. fig4
Engine room harness connector layout for R.H. Drive Model. Connector identifiers visible on diagram.
1E1(lower-left area of engine bay)
2E2(lower-left area)
3E3(lower-right area)
4E4(center-left area)
5E5(lower-right area)
6E6(lower-right area)
7E7(lower-right area)
8E8(center-left area)
9E10(upper-center area)
10E11(lower-left area)
11E12(lower-left area)
12E13(lower-left area)
13E14(lower-left area)
14E15(lower-left area)
15E16(lower-right area)
16E17(center area)
17E18(center area)
18E19(center-left area)
19E20(center area)
20E21(center area)
21E22(center-right area)
22E23(center area)
23E24(right area)
24E26(right area)
25E27(right area)
26E28(right area)
27E29(right area)
28E30(right area)
29E31(right area)
30E33(upper-right area)
31E34(upper-right area)
32E35(upper-right area)
33E36(upper-right area)
34E37(upper-right area)
35E39(upper-right area)
36E40(upper-right area)
37E41(upper-center area)
38E42(center area)
39E45(lower-center area)
40E47(lower-center area)
41E51(center-left area)
42E53(center-left area)
43Body ground(top inset — near E41)
44Body ground(middle inset — near E20)
45Body ground(bottom inset — near E24)
