SUPER MULTIPLE JUNCTION (S.M.J.)
EL-107prose procedureREMOVAL
- 1Remove fuse block retaining screws to gain access to S.M.J.
- 2Slide fuse block to the side, and remove S.M.J. retaining bolts to detach S.M.J.
INSTALLATION
- 1To install S.M.J., tighten bolts until orange "full-tight" mark appears and then retighten to specified torque as required.
SEL422L
| Specification | Value |
|---|---|
| S.M.J. retaining bolt torque | 3 - 5N·m |
| S.M.J. retaining bolt torque | 0.3 - 0.5kg-m |
| S.M.J. retaining bolt torque | 2.2 - 3.6ft-lb |
S.M.J. retaining bolt torque
3 - 5N·m
S.M.J. retaining bolt torque
0.3 - 0.5kg-m
S.M.J. retaining bolt torque
2.2 - 3.6ft-lb
CAUTION
CAUTION: Do not overtighten bolts, otherwise, they may be damaged.
