HARNESS LAYOUT — Main Harness (Cont'd) — R.H.D. rear-cabin run
EL-90component photoUnverifiedMirror of EL-86. Connector IDs are the same as L.H.D., only routing is mirrored.
Main Harness (Cont'd)
R.H. DRIVE MODEL — rear cabin
NOTE
Mirror-image of the L.H.D. rear-cabin run shown on EL-86. Three body-ground insets in the upper-left identify the physical grounding locations (M111 / M114 / M125).
Component LocationFig. fig1
R.H.D. rear-cabin connector and body-ground locations.
1Body ground M111(Inset top-left of figure)
2Body ground M114(Inset middle-left of figure)
3Body ground M125(Inset lower-left of figure)
4M101 / M125 ground cluster(Centre rear of cabin)
5M119 – M139 cluster(Parcel shelf / rear-quarter trim)
6M138 / M139 back-door pass-through(Back-door pass-through (mirrored))
