HARNESS LAYOUT — Main Harness (Cont'd) — rear-cabin run + body grounds

EL-86component photoUnverified

Continuation of EL-84 main-harness map.

Main Harness (Cont'd)

L.H. DRIVE MODEL — rear cabin

NOTE

Pictorial map of the rear-cabin run of the main harness with connector callouts M101 through ~M139. Four bottom insets show the physical location of the main rear-cabin body-ground points (M115 / M120 / M132 / similar).

Component LocationFig. fig1

Rear-cabin connector and body-ground locations.

Rotated rear-cabin / luggage-area harness map (L.H.D.) with connector callouts M101 through M139 covering the rear seat / parcel-shelf / luggage-bay region. Four insets at bottom show physical body-ground locations (M115/M120/M132 and similar).

1Body ground (rear floor pan, multiple)(Floor pan around rear-seat area)

2M101 / M125(Centre rear of cabin (passenger ground side))

3M138 / M139(Back-door pass-through)

4M115 / M120 / M132(Body ground points (insets))

5M119 – M137 cluster(Parcel shelf / rear-quarter trim)
