Diagnostic Procedure 4 — ENGINE TEMPERATURE SENSOR (Code No. 13)
EF & EC-86wiring diagramTROUBLE DIAGNOSES
Diagnostic Procedure 4
ENGINE TEMPERATURE SENSOR (Code No. 13) Wiring Schematic
Components (6)
E.C.C.S. CONTROL UNITENGINE TEMPERATURE SENSOReccs unit pin28temp sensor Aeccs unit pin30temp sensor B
Connections (2)
eccs unit pin28
eccs unit pin28temp sensor AL/OR
eccs unit pin30
eccs unit pin30temp sensor BB
Component LocationFig. fig2
Physical location of the Engine Temperature Sensor on the engine.
SEF526H
1Engine temperature sensor(lower center of photo)
