TROUBLE DIAGNOSES - Electrical Components Inspection (Cont'd)
EF & EC-123spec tableElectrical Components Inspection (Cont'd)
NOTE
*Data are reference values.
Electrical Components Inspection
| TERMINAL NO. | ITEM | CONDITION | DATA* |
|---|---|---|---|
| 111 | Pressure regulator (P.R.) control solenoid valve | Ignition switch "ON" — For approximately 3 minutes after starting engine. Water temperature is above 60°C (140°F). | 0.8 - 1.0V |
| 111 | Pressure regulator (P.R.) control solenoid valve | Ignition switch "ON" — In approximately 3 minutes after starting engine. Water temperature is above 60°C (140°F). | BATTERY VOLTAGE (11 - 14V) |
| 111 | Pressure regulator (P.R.) control solenoid valve | Ignition switch "ON" or "START". Water temperature is below 60°C (140°F). | BATTERY VOLTAGE (11 - 14V) |
111
ITEMPressure regulator (P.R.) control solenoid valve
CONDITIONIgnition switch "ON" — For approximately 3 minutes after starting engine. Water temperature is above 60°C (140°F).
DATA*0.8 - 1.0V
111
ITEMPressure regulator (P.R.) control solenoid valve
CONDITIONIgnition switch "ON" — In approximately 3 minutes after starting engine. Water temperature is above 60°C (140°F).
DATA*BATTERY VOLTAGE (11 - 14V)
111
ITEMPressure regulator (P.R.) control solenoid valve
CONDITIONIgnition switch "ON" or "START". Water temperature is below 60°C (140°F).
DATA*BATTERY VOLTAGE (11 - 14V)
Component LocationFig. fig1
E.C.U. pin connector terminal layout
SEF424H
1101(top-left row start)
2102(top-left row)
3103(top-left row)
4104(top-left row)
5105(top-left row)
6106(top-left row)
7107(top-left row)
8108(top-left row end)
9109(bottom-left row start)
10110(bottom-left row)
11111(bottom-left row)
12112(bottom-left row)
13113(bottom-left row)
14114(bottom-left row)
15115(bottom-left row)
16116(bottom-left row end)
171(top center-left row start)
182(top center-left row)
193(top center-left row)
204(top center-left row)
215(top center-left row)
226(top center-left row)
237(top center-left row)
248(top center-left row)
259(top center-left row)
2610(top center-left row end)
2711(bottom center-left row start)
2812(bottom center-left row)
2913(bottom center-left row)
3014(bottom center-left row)
3115(bottom center-left row)
3216(bottom center-left row)
3317(bottom center-left row)
3418(bottom center-left row)
3519(bottom center-left row)
3620(bottom center-left row end)
3721(top center-right row start)
3822(top center-right row)
3923(top center-right row)
4024(top center-right row)
4125(top center-right row)
4226(top center-right row)
4327(top center-right row)
4428(top center-right row)
4529(top center-right row)
4630(top center-right row end)
4731(bottom center-right row start)
4832(bottom center-right row)
4933(bottom center-right row)
5034(bottom center-right row)
5135(bottom center-right row)
5236(bottom center-right row)
5337(bottom center-right row)
5438(bottom center-right row)
5539(bottom center-right row)
5640(bottom center-right row end)
5741(top right row start)
5842(top right row)
5943(top right row)
6044(top right row)
6145(top right row)
6246(top right row)
6347(top right row)
6448(top right row)
6549(top right row)
6650(top right row end)
6751(bottom right row start)
6852(bottom right row)
6953(bottom right row)
7054(bottom right row)
7155(bottom right row)
7256(bottom right row)
7357(bottom right row)
7458(bottom right row)
7559(bottom right row)
7660(bottom right row end)
