CYLINDER HEAD
EM-16parts diagramParts DiagramFig. fig1
| # | Part Name | Notes / Torque |
|---|---|---|
| 1 | Rear oil seal | Replace — marked with X symbol |
| 2 | Cam bracket bolt | Torque: 10 - 12 N·m (1.0 - 1.2 kg·m, 7 - 9 ft-lb) |
| 3 | Camshaft | — |
| 4 | Cam bracket | — |
| 5 | Front oil seal | Replace — marked with X symbol |
| 6 | Hydraulic valve lifter | — |
| 7 | Valve cotter | — |
| 8 | Spring retainer | — |
| 9 | Valve spring | — |
| 10 | Valve oil seal | Replace — marked with X symbol |
| 11 | Valve | — |
| 12 | Washer | * (asterisk) — Direction of cylinder head bolt washer: Upper side noted |
| 13 | Cylinder head bolt | Refer to page EM-27 — marked with filled circle symbol |
| 14 | Cylinder head gasket | Replace — marked with X symbol |
| 15 | Cylinder head | — |
| Specification | Value |
|---|---|
| Cam bracket bolt torque | 10 - 12N·m |
| Cam bracket bolt torque | 1.0 - 1.2kg·m |
| Cam bracket bolt torque | 7 - 9ft-lb |
Cam bracket bolt torque
10 - 12N·m
Cam bracket bolt torque
1.0 - 1.2kg·m
Cam bracket bolt torque
7 - 9ft-lb
NOTE
*Direction of cylinder head bolt washer — Upper side indicated by diagram inset.
NOTE
Cylinder head bolt: Refer to page EM-27.
Unit: N·m (kg·m, ft-lb)
