FRONT AXLE — Wheel Hub and Knuckle
FA-12prose procedureAssembly
- 1Press new wheel bearing assembly into wheel hub from inside of rotor disc (with wheel hub).Do not press inner race of wheel bearing assembly.Do not apply oil or grease to mating surfaces of wheel bearing outer race and wheel hub. Be careful not to damage grease seal.
SFA217A - 2Install circular clip into groove of wheel hub.
SFA218A - 3Apply multi-purpose grease to sealing lip.
| Specification | Value |
|---|---|
| Maximum load P (pressing wheel bearing assembly)Pressing new wheel bearing assembly into wheel hub | 29 kN (3 t, 3.3 US ton, 3.0 Imp ton)kN / t / US ton / Imp ton |
Maximum load P (pressing wheel bearing assembly)Pressing new wheel bearing assembly into wheel hub
29 kN (3 t, 3.3 US ton, 3.0 Imp ton)kN / t / US ton / Imp ton
CAUTION
CAUTION:
• Do not press inner race of wheel bearing assembly.
• Do not apply oil or grease to mating surfaces of wheel bearing outer race and wheel hub. Be careful not to damage grease seal.
