ENGINE LUBRICATION SYSTEM
LC-3prose procedureLubrication Circuit
Lubrication Circuit
Rendering diagram…
Oil Pressure Check
WARNING
Be careful not to burn yourself, as the engine and oil may be hot.
WARNING
Oil pressure check should be done in "Neutral" gear position.
Oil Pressure Check
- 1Check oil level.
- 2Remove oil pressure switch.
SLC199A
Component LocationFig. fig2
Engine compartment showing oil filter and oil pressure switch locations
SLC199A
1Oil filter(upper area)
2Oil pressure switch(lower area near oil filter)
